Telycam Drive+ SE 20x NDI®|HX2, USB3.0, 1080p

Price:

kr 6 264,30
  2. Shop
  3. Telycam Drive+ SE 20x NDI®|HX2, USB3.0, 1080p
Dugr Vagn mobil tralle med el hev/senk
Dugr Vagn mobil tralle med el hev/senk
kr 6 900,00
kr 6 900,00
Telycam Meet+ 100 – 4K PDAF Bullet Webcam (USB2.0)
Telycam Meet+ 100 – 4K PDAF Bullet Webcam (USB2.0)
kr 1 030,00
kr 1 030,00

Telycam Drive+ SE 20x NDI®|HX2, USB3.0, 1080p

https://www.dugr.co/web/image/product.template/21461/image_1920?unique=73f57ab
12 sold in last 24 hours

kr 6 264,30 6264.3 NOK kr 6 264,30

kr 6 264,30

Not Available For Sale

4 people are viewing this right now
  • Produsent
  • Velg farge
  • Valgfri videoutgang
  • Modellserie

Denne kombinasjonen eksisterer ikke.

Kontakt oss
Telycam
Telycam

Telycam utvikler avanserte videokameraer som forbedrer samhandling, kommunikasjon og samarbeid. Med innovative PTZ-kameraer og webcams optimalisert for direktesending, streaming og videokonferanser, leverer Telycam brukervennlige og pålitelige løsninger for profesjonelle miljøer.

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Optics & Imaging

Specification

Details

SKU:

Black 3G-SDI: TLC-300-IP-20(NDI)-SE-SDI-BL | White 3G-SDI: TLC-300-IP-20(NDI)-SE-SDI-WH
Black HDMI: TLC-300-IP-20(NDI)-SE-HDMI-BL | White HDMI: TLC-300-IP-20(NDI)-SE-HDMI-WH

Image Sensor

1/2.8-inch, 2.4MP CMOS sensor

Optical Zoom

20x optical zoom

Lens

f = 4.9mm ~ 98mm, F1.5 ~ F3.0

Horizontal Field of View

60° (Wide) to 3.2° (Tele)

Vertical Field of View

34.14° to 1.12°

Diagonal Field of View

67.08° to 2.27°

Minimum Working Distance

1.0m

Signal-to-Noise Ratio (S/N)

≥50dB

Video Output & Streaming

Specification

Details

HDMI/3G-SDI Output

1920×1080p60/50/30/25/59.94/29.97/24/23.98; 1920×1080i60/50/59.94; 1280×720p60/50/30/25/59.94/29.97

NDI®|HX Output

1920×1080@360fps; 1280×720@360fps; 1024×576@360fps; 640×360@360fps (low bandwidth mode)

USB 3.0 Output

1920×1080p60/50/30/25; 1280×720p60/50/30; 1280×720p25; 1024×576p30; 960×540p30; 640×360p30; 512×288p30

IP Streaming Codec

H.264, H.265

Bitrate Control

VBR, CBR

Bitrate Range

1024Kbps~16384Kbps

Network Port Speed

1000 Mbps

Streaming Protocols

NDI®|HX, SRT, HTTP, RTSP, RTMP, DHCP, ONVIF, VISCA over IP, VISCA TCP, VISCA UDP, Pelco P/D, RTP Multicast, HTML

Image Processing

Specification

Details

Noise Reduction

2D & 3D

Minimum Illumination

0.7 Lux (50 IRE Max AGC, 1/30, F1.8)

White Balance Modes

Auto, Manual, ATW, Push, Indoor, Outdoor, Sodium, Fluorescent

Exposure Modes

Auto, Manual, Shutter Priority, Iris Priority, Brightness Priority

Anti-Flicker Options

OFF, 50Hz, 60Hz

Image Flip/Mirroring

Supported

Focus Control

Auto/Manual

Iris Control

Auto/Manual

Electronic Shutter Control

Auto/Manual

Gamma Correction

Supported

Backlight Compensation

Supported

Pan, Tilt & Control

Specification

Details

Pan Rotation Angle

-170° to +170°

Tilt Rotation Angle

-30° to +90°

Pan Speed Range

0.1° to 120°/s

Tilt Speed Range

0.1° to 80°/s

Number of Presets (Remote)

10

Number of Presets (Serial Port)

128

Control Interfaces

RS232, RS485, NDI®|HX, USB 3.0 (UVC1.5), USB 2.0 (UVC1.1)

Connectivity & I/O

Specification

Details

Video Output Ports

HDMI or 3G-SDI (selectable), USB 3.0

Audio Input (Stereo 3.5mm Line-In)

Supported

Tally Light

Supported

Daisy Chain Support

Supported

Power & Environmental

Specification

Details

Power Input Voltage

DC 12V, PoE+ (IEEE802.3at)

Operating Temperature

-10℃ to 50℃

Operating Humidity

≤80%

Physical & Design

Specification

Details

Dimensions (L×W×H)

220mm × 190mm × 173mm

Net Weight

1.35 kg

Color Options

Black, White



Merkevare
Produsent Telycam
Modellserie Drive+
Teknisk
Valgfri videoutgang 3G-SDI or HDMI
Varianter
Velg farge Svart or Hvit
